FS-Curtis NxD15 Fixed-Speed Rotary Screw Air Compressor - 20 HP / 15 kW

FS-Curtis NxD15 Fixed-Speed Rotary Screw Air Compressor - 20 HP / 15 kW Specification

Noise Level
72 db

Power Consumption
15 Kilowatt (kW)

Usage
Continuous industrial compressed air

Size
20 HP / 15 kW

Height
1515 Millimeter (mm)

Product Type
Fixed-speed rotary screw air compressor

Power Source
Electric

Weight
610 Kilograms (kg)

Voltage
400 Volt (v)

Color
White and grey

Length
1250 Millimeter (mm)

Dimensions
1250 x 880 x 1515 Millimeter (mm)

Width
880 Millimeter (mm)

Configuration
Stationary enclosed rotary screw

Air Flow Capacity
88 Cubic Feet Per Minute (ft3/min)

Driven Method
Direct drive

Working Presssure
7 to 12 bar

Motor
15 kW IE3 electric motor

FS-Curtis NxD15 Fixed-Speed Rotary Screw Air Compressor - 20 HP / 15 kW About

FS-Curtis NxD15 fixed-speed rotary screw air compressor with a 15 kW (20 HP) IE3 motor for continuous industrial compressed-air duty. Available in 7, 8, 10 and 12 bar versions at 400 V / 50 Hz. Free-air delivery is 88 CFM at 7 bar, 81 CFM at 8 bar, 74 CFM at 10 bar and 64 CFM at 12 bar. Noise level is approximately 72 dB(A), dimensions are 1250 x 880 x 1515 mm and machine weight is approximately 610 kg. The listed price is the July 2025 manufacturer list price for the standard NxD15 compressor, ex-works Pune; GST, packing, freight, installation and optional accessories are additional and current price should be reconfirmed before ordering.
